# latitude and longitude

## High-Level Explanation

Latitude and Longitude using the WGS84 latitude-longitude projection (see e.g. <https://geopandas.org/en/stable/docs/user_guide/projections.html>) from the GPS system.

## Enables

* Distance
  * Distance between successive points
  * This code transforms the GPS points from the coordinate reference system (CRS) of WGS84 into a meter-based projection (e.g.  <https://epsg.io/6340> is appropriate for California and nearby states and <https://epsg.io/32118> is appropriate for New York, as used below).

    <pre class="language-python" data-overflow="wrap" data-line-numbers><code class="lang-python">import geopandas as gpd

    gdf['dist_to_prev_pt'] = gdf['geometry'].to_crs('EPSG:32118').distance(gdf['geometry'].shift(1).to_crs('EPSG:32118'))
    gdf['dist_to_prev_pt_shift'] = gdf['dist_to_prev_pt'].shift(1)
    </code></pre>
  * Using the Haversine distance between points along with the difference in time between those points, the speed can be estimated.&#x20;
* Location types
  * Spatial joins to relevant localities, such as time zone, states, and population density (see <https://www.census.gov/geographies/mapping-files/time-series/geo/tiger-line-file.html> for some relevant US Census shapefiles).
* Map Matching (must also have timestamp)
  * Open-source map matching (such as Valhalla) or paid services (such as MapBox) can be used to "snap" the GPS coordinates to roadways.
  * MapBox Example: First, the `latitudes` and `longitudes` must be formatted in a way that the MapBox endpoint will accept. Note that `[::4]` takes every fourth coordinate, as MapBox accepts at most 100 coordinates at a time and giving coordinates roughly every 20\*4 = 80 seconds is generally sufficient for map matching to the road network. (Note that a MapBox api key is required). See the code appendix below for the `decode` function.
    * <pre class="language-python" data-overflow="wrap" data-line-numbers><code class="lang-python"><strong>import requests
      </strong>
      lngs = gdf['longitude'].tolist()[::4]
      lats = gdf['latitude'].tolist()[::4]
      coordinates = ';'.join([str(i) + ',' + str(j) for i,j in zip(lngs,lats)])
      url = f'https://api.mapbox.com/matching/v5/mapbox/driving-traffic/{coordinates}?access_token={api_key}'
      response = requests.get(url)
      </code></pre>
    * The `response` contains information about the roads that this set of coordinates matched to. For example:
    * <pre class="language-python" data-overflow="wrap" data-line-numbers><code class="lang-python">response.json()['matchings'][4]
      > {'confidence': 0.93516,
       'weight_name': 'auto',
       'weight': 222.003,
       'duration': 201.324,
       'distance': 5750.37,
       'legs': [{'via_waypoints': [],
         'admins': [{'iso_3166_1_alpha3': 'USA', 'iso_3166_1': 'US'}],
         'weight': 112.387,
         'duration': 96.623,
         'steps': [],
         'distance': 2720.261,
         'summary': 'US 23 North'},
        {'via_waypoints': [],
         'admins': [{'iso_3166_1_alpha3': 'USA', 'iso_3166_1': 'US'}],
         'weight': 109.616,
         'duration': 104.701,
         'steps': [],
         'distance': 3030.11,
         'summary': 'BL I 94, US 23 North'}],
       'geometry': 'gsv`Gtsw}Ncq@jDsk@_Lew@j@_RRw`@kCi[}a@uJeG}_AO'}
      </code></pre>
    * And this `geometry` decodes to&#x20;
    * <pre class="language-python" data-overflow="wrap" data-line-numbers><code class="lang-python">[[i[0]*10,i[1]*10] for i in decode(response.json()['matchings'][4]['geometry'])]
      > [[-83.68459, 42.227880000000006],
       [-83.68544999999999, 42.2359],
       [-83.68337, 42.24304],
       [-83.68359, 42.25203],
       [-83.68369, 42.25507],
       [-83.68299, 42.260470000000005],
       [-83.67739999999999, 42.265],
       [-83.67609, 42.26687],
       [-83.67601, 42.27726]]
      </code></pre>
    * Further, the sum of meters driven on each of the roadways using
    * <pre class="language-python" data-line-numbers><code class="lang-python">lst = []
      for i in range(len(response.json()['matchings'])):
          lst.append(pd.DataFrame(response.json()['matchings'][i]['legs']))
      pd.concat(lst).groupby('summary')['distance'].sum()
      >   BL I 94, US 23 North                                                  3030.110
          Broadway Street                                                         97.029
          I 94 East                                                            23498.362
          I 94 East, I 94 West                                                  9355.541
          I 94 West                                                            25963.642
          I 94 West, I 94 East                                                  7703.051
          John D Dingell Drive                                                  2125.649
          John D. Dingell Drive, John D Dingell Drive                           7828.364
          John D. Dingell Drive, Long-term Parking / International Arrivals      978.600
          Merriman Road                                                         1817.140
          Plymouth Road                                                         1292.209
          Plymouth Road, Devon Circle                                           2753.524
          Plymouth Road, US 23 South                                            6734.600
          US 23 North                                                           2720.261
          US 23 South                                                           5261.977
          W. G. Rogell Drive                                                    1845.754
      </code></pre>
  * Valhalla Example: To hit the open Valhalla endpoint (see: <https://valhalla.github.io/valhalla/api/map-matching/api-reference/>). Alternatively, Valhalla can be hosted on a server (see e.g. <https://water-gis.com/en/setups/valhalla/setup-valhalla/>). At the bottom is a sum of the roads travelled in kilometers. Note that the public Valhalla endpoint seems to limit the length of the output (here, the return trip is truncated off the output of the map matching service).
    * <pre class="language-python" data-overflow="wrap" data-line-numbers><code class="lang-python">req = gdf[['latitude','longitude']].rename(columns={'latitude':'lat','longitude':'lon'})
      lst = []
      for i in req.index:
          lst.append({"lat":req.loc[i,'lat'],'lon':req.loc[i,'lon'], 'type':'via'})

      lst[0]['type'] = 'break'
      lst[-1]['type'] = 'break'
      dct = {"shape" : lst}
      dct['costing'] = 'auto'
      dct['shape_match'] = "map_snap"
      dct['units'] = 'miles'

      url = 'https://valhalla1.openstreetmap.de/trace_route'

      response = requests.post(url, json = dct)

      street_names = []
      lengths = []
      ms = response.json()['trip']['legs'][0]['maneuvers']

      for m in ms:
          try:
              street_names.append(m['street_names'])
              lengths.append(m['length'])
          except KeyError:
              pass

      temp = pd.DataFrame()
      temp['street_name'] = street_names
      temp['length'] = lengths
      temp['street_name'] = temp['street_name'].map(lambda x: x[0])

      shape_gdf = gpd.GeoDataFrame(decode(response.json()['trip']['legs'][0]['shape']))
      shape_gdf['geometry'] = gpd.geoseries.points_from_xy(x = shape_gdf[0], y = shape_gdf[1])

      temp.groupby('street_name')['length'].sum()

      > street_name
      Broadway Street                                0.085
      Devon Circle                                   0.233
      Huron Parkway                                  0.625
      I 94 East                                     17.561
      Long-term Parking / International Arrivals     0.496
      Merriman Road                                  2.404
      Plymouth Road                                  3.141
      Traverwood Drive                               0.272
      US 23 South                                    5.290
      </code></pre>

## Enabled By

## Known Quirks

* "Teleportation": Occasionally, jumps in location that are physically impossible occur due to some sort of error in the data collection. As a guide, the Haversine distance between successive points, divide by the time difference, and obtain a rough upper bound for the speed the vehicle would have to travel between the successive points in the given time. 75 meters per second is used as the sanity check for this `derived_speed` (see code appendix and example below).&#x20;
  * This may be due to a GPS connection error, as there are many instances where the reported `speed` is greater than 0 but the `latitude` and `longitude` do not change.&#x20;
* Sign error: On rare occasion, the sign of `latitude` has been flipped, resulting in coordinates that take truly place in the United States appearing as though they take place in Asia.

## Cases

* SmartCar
  * Data points are captured every 4 hours, so trips will generally not be captured
* AutoPi
  * Data points are generally captured every 20 seconds of vehicle operation
* Tesla
  * Data points are generally captured every 60 seconds while the vehicle is on or charging, but are sometimes more frequent.

## Code Appendix

{% code title="decode\_polyline.py" overflow="wrap" lineNumbers="true" %}

```python
#decode an encoded string
def decode(encoded):
  decoded = []
  previous = [0,0]
  i = 0
  #for each byte
  while i < len(encoded):
    #for each coord (lat, lon)
    ll = [0,0]
    for j in [0, 1]:
      shift = 0
      byte = 0x20
      #keep decoding bytes until you have this coord
      while byte >= 0x20:
        byte = ord(encoded[i]) - 63
        i += 1
        ll[j] |= (byte & 0x1f) << shift
        shift += 5
      #get the final value adding the previous offset and remember it for the next
      ll[j] = previous[j] + (~(ll[j] >> 1) if ll[j] & 1 else (ll[j] >> 1))
      previous[j] = ll[j]
    #scale by the precision and chop off long coords also flip the positions so
    #its the far more standard lon,lat instead of lat,lon
    decoded.append([float('%.6f' % (ll[1] * inv)), float('%.6f' % (ll[0] * inv))])
  #hand back the list of coordinates
  return decoded
```

{% endcode %}

Note that `odometer` is not available for every vehicle, nor every record for every vehicle, so the Haversine distance between successive points can be used as a rough lower bound of distance travelled.

{% code title="clean\_data.py" overflow="wrap" lineNumbers="true" fullWidth="false" %}

```python
def clean_df(df):
    gdf = gpd.GeoDataFrame(df)
    gdf = gdf.loc[gdf['latitude'].notna()].reset_index(drop = True)
    gdf = gdf.loc[gdf['odometer'].notna()].reset_index(drop = True)

    gdf['geometry'] = gpd.GeoSeries.from_xy(x=gdf['longitude'],y=gdf['latitude'])
    gdf = gpd.GeoDataFrame(gdf)
    gdf.crs = "EPSG:4326"

    gdf['timestamp'] = pd.to_datetime(gdf['timestamp'])
    gdf = gdf.sort_values('timestamp').reset_index(drop = True)

    gdf['odometer_diff'] = gdf['odometer'].diff()

    gdf['timestamp_diff'] = gdf['timestamp'] - gdf['timestamp'].shift(1)
    gdf['timestamp_diff_second'] = (gdf['timestamp_diff']/np.timedelta64(1,'s')).fillna(20)
    gdf['derived_speed'] = 1000*gdf['odometer_diff']/gdf['timestamp_diff_second']

    initial_size = gdf.shape[0]
    while gdf['derived_speed'].max() > 75:
        gdf = gdf.loc[(gdf['derived_speed'] < 75)]
        gdf['haversine_dist_shift'] = gdf['geometry'].to_crs('EPSG:6340').\
            distance(gdf['geometry'].shift().to_crs('EPSG:6340')).fillna(0)/1000

        gdf['timestamp_diff'] = gdf['timestamp'] - gdf['timestamp'].shift(1)
        gdf['timestamp_diff_second'] = (gdf['timestamp_diff']/np.timedelta64(1,'s')).fillna(20)
        gdf['derived_speed'] = 1000*gdf['haversine_dist_shift']/gdf['timestamp_diff_second']


        gdf['haversine_dist_shift_prev'] = -gdf['geometry'].to_crs('EPSG:6340').\
            distance(gdf['geometry'].shift(-1).to_crs('EPSG:6340')).fillna(0)/1000

        gdf['timestamp_diff_prev'] = gdf['timestamp'] - gdf['timestamp'].shift(-1)
        gdf['timestamp_diff_second_prev'] = (gdf['timestamp_diff_prev']/np.timedelta64(1,'s')).fillna(20)
        gdf['derived_speed_prev'] = 1000*gdf['haversine_dist_shift_prev']/gdf['timestamp_diff_second_prev']

def clean_df_no_odometer(df):
    gdf = gpd.GeoDataFrame(df)
    gdf = gdf.loc[gdf['latitude'].notna()].reset_index(drop = True)

    gdf['geometry'] = gpd.GeoSeries.from_xy(x=gdf['longitude'],y=gdf['latitude'])
    gdf = gpd.GeoDataFrame(gdf)
    gdf.crs = "EPSG:4326"

    gdf['timestamp'] = pd.to_datetime(gdf['timestamp'])
    gdf = gdf.sort_values('timestamp').reset_index(drop = True)

    gdf['haversine_dist_shift'] = gdf['geometry'].to_crs('EPSG:6340').\
        distance(gdf['geometry'].shift().to_crs('EPSG:6340')).fillna(0)/1000
    gdf['timestamp_diff'] = gdf['timestamp'] - gdf['timestamp'].shift(1)
    gdf['timestamp_diff_second'] = (gdf['timestamp_diff']/np.timedelta64(1,'s')).fillna(20)
    gdf['derived_speed'] = 1000*gdf['haversine_dist_shift']/gdf['timestamp_diff_second']

    initial_size = gdf.shape[0]
    while gdf['derived_speed'].max() > 75:
        gdf = gdf.loc[(gdf['derived_speed'] < 75)]
        gdf['haversine_dist_shift'] = gdf['geometry'].to_crs('EPSG:6340').\
            distance(gdf['geometry'].shift().to_crs('EPSG:6340')).fillna(0)/1000

        gdf['timestamp_diff'] = gdf['timestamp'] - gdf['timestamp'].shift(1)
        gdf['timestamp_diff_second'] = (gdf['timestamp_diff']/np.timedelta64(1,'s')).fillna(20)
        gdf['derived_speed'] = 1000*gdf['haversine_dist_shift']/gdf['timestamp_diff_second']

    gdf = gdf.sort_values('timestamp').reset_index(drop = True)
    return gdf
```

{% endcode %}

## Visualizations with Explanations

<figure><img src="https://3212476574-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2Foh9c3w7RI0Bl5tVCxcyz%2Fuploads%2FsOeb4WWn1l1lKNtlEDic%2Fimage.png?alt=media&#x26;token=1f749a64-227d-484b-8cb1-4c6b5d503f34" alt=""><figcaption><p>GPS coordinates on a map color coded by the distance between successive points</p></figcaption></figure>

<figure><img src="https://3212476574-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2Foh9c3w7RI0Bl5tVCxcyz%2Fuploads%2FpmXQYC5BVpFk1yynNdsd%2Fimage.png?alt=media&#x26;token=780431a7-f512-4de7-8429-85dd842d363d" alt=""><figcaption><p>GPS coordinates on a map color coded by the US Census population density (C: micropolitan , R: Rural, U: Urban)</p></figcaption></figure>

<figure><img src="https://3212476574-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2Foh9c3w7RI0Bl5tVCxcyz%2Fuploads%2Fo2gQC0DdfjcycerajrAM%2Fimage.png?alt=media&#x26;token=39f3f596-585d-43d7-910d-3a9771955c50" alt=""><figcaption><p>Example SmartCar data</p></figcaption></figure>

<figure><img src="https://3212476574-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2Foh9c3w7RI0Bl5tVCxcyz%2Fuploads%2FuJ4wNzcYiuT6gVEp8IKU%2Fimage.png?alt=media&#x26;token=11affe7d-b70e-4a57-82e9-a4876accf19f" alt=""><figcaption><p>Histogram of time between <strong>Tesla</strong> records for an example vehicle</p></figcaption></figure>

<figure><img src="https://3212476574-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2Foh9c3w7RI0Bl5tVCxcyz%2Fuploads%2FcS4kdEoC9mR6Ww0B4Jud%2Fimage.png?alt=media&#x26;token=d4940a7c-097c-410f-ae70-2b13d017e8d1" alt=""><figcaption><p>Histogram of time between <strong>AutoPi</strong> records for an example vehicle</p></figcaption></figure>

<figure><img src="https://3212476574-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2Foh9c3w7RI0Bl5tVCxcyz%2Fuploads%2FuWx7Zxaf1BQsLiYYqc8G%2Fimage.png?alt=media&#x26;token=82725690-e764-4732-b7e6-7ffa21a6fc37" alt=""><figcaption><p>Map matched coordinates (red: snapped coordinated, blue and green: original coordinates, where this trip starts in blue and ends in green)</p></figcaption></figure>

<figure><img src="https://3212476574-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2Foh9c3w7RI0Bl5tVCxcyz%2Fuploads%2FQpUYVfO5pPs07XmBnwt5%2Fimage.png?alt=media&#x26;token=d29177b1-97d0-41fe-8788-d41531758268" alt=""><figcaption><p>The blue coordinates (Valhalla map matched data) going towards the airport but the return trip is not captured (red: original coordinates)</p></figcaption></figure>

<figure><img src="https://3212476574-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2Foh9c3w7RI0Bl5tVCxcyz%2Fuploads%2FuZGHnGQugwC6QKChRa92%2Fimage.png?alt=media&#x26;token=d8406ecc-51f1-470c-97b5-a8b54dbfa7ef" alt=""><figcaption><p>Example of "Teleportation", color coded by <code>derived_speed</code></p></figcaption></figure>

<figure><img src="https://3212476574-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2Foh9c3w7RI0Bl5tVCxcyz%2Fuploads%2FwwLmP7mrn2JxPWZD2gMr%2Fimage.png?alt=media&#x26;token=9e25d057-a246-40bb-877a-978a5557279c" alt=""><figcaption><p>Example of "Teleportation", color coded by vehicle-reported <code>speed</code></p></figcaption></figure>
